Plaster finishing machine
PFM
Item no. 30000
Applications
- Machining plaster, lime-cement render and clay plaster
- Abrading render and plaster
- Gypsum multi finish
- Machining of fine finish plaster
- Smoothing concrete elements
- Sponging filler compounds
Advantages
- Light weight
- Uniform structure due to large operation area
- Time- and cost-saving (approx. 50 % time saving compared to manual work)
- Continuous speed control (optimal adjustment to each application)
Specifications
The plaster finishing machine for purists - without any frills whatsoever. That makes the PFM the lightest plaster finishing machine in our portfolio (hand tool only 1,3 kg). This is ensured by the well-established and reliable Rokamat concept: the separation of hand tool and motor (the latter is worn on a belt or shoulder strap). In addition to reducing weight, this feature also largely protects the motor from soiling.
What once had to be done laboriously by hand can now easily be done by machine. Select any speed between 75-340 min-1, thus adapting it to fit your requirements.
The PFM is not just suited for plaster finishing. Thanks to a wide scope of accessories it is also ideal for smoothing of concrete elements and gypsum multi finish.
The special connection tube allows for an unobstructed view on the working surface and makes it possible to reach higher areas, too.
Whether it is plaster, lime-cement render, clay plaster, synthetic resin plaster, mineral plaster or silicate plaster - the PFM is just itching to get to work!
The PFM was formerly knows as ROKAMAT DRY.
Fields of application
- Plaster finishing ♦ ♦ ♦
- Flattening fresh concrete ♦ ♦
- Working on scaffolding ♦ ♦ ♦
suited ♦ / well suited ♦♦ / very well suited ♦♦♦
Technical data
| Power consumption | 1 000 W |
| Idle engine speed | 75-340 rpm |
| Net weight hand tool | 1,3 kg |
| Total weight1) | 4,9 kg |
| Accessory-Ø | 250/350 mm |
Scope of supply
| Plaster finishing machine |
| Strap |
| Supporting plate (velcro system) |
| Sponge disc Ø 350 mm (Item no. 49300) |
| Case |
Ø 350 mm Supporting plate with Velcro
Velcro System for Ø 350 mm
| Description | No. |
|---|---|
| Supporting Plate with Velcro | 48000 |
Ø 350 mm Rubbing plates
| Description | No. |
|---|---|
| Rubbing plate with Velcro perforated | 48100 |
| Rubbing plate with Velcro smooth | 48200 |
- For smoothing mortar.
- Smooth plate also for Fine Finish Plaster.
Ø 350 mm Sponge discs
| Description | No. |
|---|---|
| Sponge with Velcro, coarse | 49300 |
| Sponge with Velcro, fine | 49400 |
| Sponge on supporting backing with Velcro, coarse | 48300 |
| Sponge on supporting backing with Velcro, fine | 48400 |
- Sponge disc for traditional finish plaster such as multi finish.
- Sponges on supporting plates can be worked off completely.
Ø 350 mm Sponge discs superfine
| Description | No. |
|---|---|
| Sponge with Velcro, superfine | 49500 |
| Sponge on supporting plate with Velcro, superfine | 48500 |
- For generating a fine surface structure.
- Sponges on supporting plates can be worked off completely.
Ø 350 mm LEMON Hydro sponge ring
| Description | No. |
|---|---|
| LEMON Hydro sponge ring with Velcro | 48810 |
- NEW! For a perfect surface structure!
Ø 350 mm STRUCTURA Hydro sponge ring
| Description | No. |
|---|---|
| STRUCTURA Hydro sponge ring with Velcro | 48800 |
- For a perfect surface structure!
Ø 350 mm Sponge discs blue
| Description | No. |
|---|---|
| Sponge with Velcro, blue | 49800 |
- For fine plastering (very fine grain).
Ø 350 mm Sponge discs brown
| Description | No. |
|---|---|
| Sponge with Velcro, brown | 49900 |
- For fine plastering (very fine grain).
Ø 350 mm Felt disc
| Description | No. |
|---|---|
| Felt Disc with Velcro | 49600 |
- Rubbing interior / exterior lime-cement render surfaces.
Ø 350 mm Smoothing disc
| Description | No. |
|---|---|
| Smoothing disc with Velcro | 34550 |
- For abrading render and plaster after setting.
Ø 250 mm Sponge discs
| Description | No. |
|---|---|
| Sponge disc, coarse | 33000 |
| Spare sponge, coarse | 33100 |
| Sponge disc, fine | 33400 |
| Spare sponge, fine | 33500 |
- For sponging plaster and lime-cement render.
- For generating a fine surface structure.
- Sponging filler compounds and clay plaster.
Trowels for smoothing concrete
| Description | No. |
|---|---|
| Trowel with velcro, smooth (stainless steel) -longlife- Ø 350 mm | 48900 |
| Trowel with velcro, smooth (stainless steel) -longlife- Ø 215 mm | 34900 |
| Base plate (to use with trowel Ø 215 mm) | 69110 |
- Smoothing concrete elements.
Ø 450 mm Trowel
| Description | No. |
|---|---|
| Patented Trowel | 34300 |
- NEW! Finishing wall renders of all types.
| Description | No. |
|---|---|
| Premium package gypsum multi finish: Sponge on plastic board, trowel, supporting plate and polishing pad | 34305 |
Shoulder strap
| Description | No. |
|---|---|
| Shoulder strap | 05100 |
- With shoulder pad and length adjustment.
By loading the video, you agree to YouTube's privacy policy.
Learn more
By loading the video, you agree to YouTube's privacy policy.
Learn more
By loading the video, you agree to YouTube's privacy policy.
Learn more
1) Rounded total weight without accessories
Plaster Finishing Machines comparison
 PFM 5 |
 PFM |
 PFM W |
 PFM WT |
 PFM C |
PFM CX |
|
|---|---|---|---|---|---|---|
| Power consumption | 1 000 W | 1 000 W | 1 000 W | 600 W | 18 V / 5,2 Ah (Li-Ion) optional 18 V / 8,0 Ah (LiHD) | 18 V / 5,2 Ah (Li-Ion) optional 18 V / 8,0 Ah (LiHD) |
| Idle engine speed rpm | 75-340 | 75-340 | 75-340 | 75-340 | 230 | |
| Weight hand tool kg | approx. 3,4 | approx. 1,3 | approx. 2,0 | approx. 1,7 | approx. 2,8 | |
| Accessory Ø | 250 / 350 | 250 / 350 | 250 / 350 | 350 | 250 / 350 | |
| Container | 6 l | |||||
| Plaster finishing | ♦♦♦ | ♦♦♦ | ♦♦♦ | ♦♦♦ | ♦♦♦ | |
| Flattening fresh concrete | ♦♦ | ♦♦ | ♦♦ | ♦♦ | ♦♦ | |
| Working on scaffolding | ♦♦♦ | ♦ | ♦ | ♦♦ | ♦♦♦ |
Suitability levels: suited ♦ / well suited ♦♦ / very well suited ♦♦♦
